Main Features:
Accept upssss to 4×HDMI inputs, 2×DP inputs, 1×HDMI 2.0 out
Support 4K 60 frmps/HDCP2.2/4:4:4 in and out
Combines up to four 4K video inputs onto a single stunning display
Windows layout can be customized as wanted
Available to capture a certain part of source to display
Mouse roaming, seamlessly navigate the mouse to any windows to operate
Independent audio and video source selection
Controlled by RS232, web page, front panel
System Diagram
Specifications
Video | |
Input Interface | 4 × HDMI IN, 2 x DP IN. 2xUSB 2.0 IN (MS641KVM-2) |
Input Specification | HDMI：HDMI 2.0a DisplayPort: DP1.2a HDCP: HDMI 2.0, DP 1.4 USB: USB 2.0 (MS641KVM-2) |
Input Resolution | Up to 3840 x 2160@60Hz |
Input Electrical Level | 0.5-1.0 V peak to peak value |
Output Interface | 1 x HDMI OUT, 6xUSB 2.0 OUT (MS641KVM-2) |
Output Specification | HDMI 2.0 |
Output Resolution | Up to 3840 x 2160@60Hz |
Output Impedance | 100 Ω |
DDC Signal | 1.2 V peak to peak value |
Audio | |
Input Interface | 6 x 3.5mm stereo jack |
Output Interface | 1 x 3.5mm stereo jack 1 x optical fiber terminal |
General | |
Power Supply | 110~240V AC |
Power Dissipation | 15W |
Control Mode | RS232，LAN |
Work Temperature | 0°C to 35°C (32°F to 95°F) 10% to 90%, no condensation |
Storing Temperature | -20°C to 70°C (-4°F to 140°F) 10% to 90%, no condensation |
Product size (L x W x H) | 440mm x 272mm x 43.5mm |
Product Weight | 3.16kg |
