WMT-C1 Key Advantages
With popular USB-C interface
APP-free
Plug and play
Easy to use
Specifications
Supported Formats | |
Video Input Formats | Compliant with DP 1.2 for 1.62Gbps, 2.7Gbps ,5.4Gbps |
HDCP | HDCP1.3 |
Video Input Resolution | VESA, maximum 2560x1440 |
Video input timing | 1920x1080,1680x1050, 1600x900,1440x900,1400x1050,1366x768,1280x1024,1280x800,1280x720,1024x768,1920x1200,1600x1200, 2560x1440 |
Video Output Formats | 1 x Wireless |
Audio Input Formats | DP 2CH PCM |
Audio Output Formats | WIFI 11b/g/n/ac |
Inputs Connectors | |
USB Input | USB type C (USB 2.0 only) |
Wireless Specification | |
Wireless transmission protocol | WIFI IEEE 802.11 a/g/n/ac |
WIFI Frequency band | 2.4 GHz & 5 GHz |
WIFI Antenna | MIMO 2x2 |
WIFI Data rate | Up to 1200Mbps |
Features | |
Video Capacity | Wireless Transmission 1080P@ 60Hz, 2560x1440 30Hz |
Distance | Typical: 35m without obstacle between WMT3-H and WMS |
Latency | ＜100ms |
Control | |
Button | Capacitive touch Key and vibration |
Indicator | Green/Red/color back-lit LED indicator |
Mechanical | |
Round Unit Dimensions | without cable: 65mm x 15mm x80mm |
Weight | ~0.2lbs (~85g) |
Surface finish | 1~2mm plastic with matte black finish |
Environment | |
Operating Temperature | -4° to +113 ° F (-20° C to +45° C) |
Storage Temperature | -4° to +140° F (-20° C to to +60° C) |
Relative humidity | 20%~ 85% RH（no condensation） |
Power | |
Power Input | USB Internal 5V |
Power Consumption | 3W (max.) |
